Chelonus bosonohyi
authorTobias & Lozan 2006
synonyms
body
shapeBody length: 3.1mm. [TL4].
colorBody black [TL4].
head
shapeIn dorsal view roundly narrowed behind eyes, almost twice as broad as long (57 : 29), 1.2 times as broad as mesosoma. In frontal view 1.1 times as broad as high. Ocelli small, not widely separated, POL = 1.5 times OOL. Temples as long as eye [TL4].
sculptureHead behind eye and face finely transversely striate. Frons with fine concentrical sculpture. Clypeus largely punctate and not shining [TL4].
colorLabiomaxillary complex dark brown [TL4].
antenna
shape ♀
shape ♂Antennae with 23 segments, almost as long as body length; scape 3 times as long as wide; 3rd segment about 3.5 times as long as wide, apical segments 2-2.5 times as long as wide [TL4].
color
mesosoma
shapeIn dorsal view almost as broad as carapace. In lateral view 1.8 times as long as high and almost as long as length of carapace. Propodeum with transversal carina, lateral tubercles small. [TL4].
sculptureMesonotum [mesosoma?] rugose punctate. Scutum [Mesonotum?] anteriorly granulate punctate, area before scutellum with some rugae. Scutellum largely not roughly sculptured, centrally shining. Propodeum granulate rugose [TL4].
color
legs
shapeHind femora 3.5 times as long as broad. Outer spur of hind tibiae longer than inner spur, almost reaching half of metatars [TL4]
sculpture
colorfore coxae dark-brown, hind coxae black; fore femora brown with yellowish apices, hind femora dark-brown; fore tibiae yellowish, hind tibiae dark-brown with a central brown spot; all tarsi brown [TL4].
wings
shapeMarginal cell in forewing comparatively large, 1-R1 as long as pterostigma. Second submarginal cell half the size of the marginal cell. 3-SR as long as r, 4 times shorter than SR1 [TL4].
colorForewings slightly infuscate. Pterostigma, costal vein and and metacarpus brown, other veins brownish [TL4].
metasoma
shapeCarapace elongate, almost twice as long as maximum width; apicoventrally incurved for one-tenth of its length [TL4].
sculptureCarapace granulate with thin longitudinal rugae spanning half its length [TL4].
color
♀ ovipositor
♂ apertureaperture oval and small, in rear view of posterior end about 0.27 of width of carapace [TL4].
other info
distributionCZ [FE].
remarks
hosts
type description
Microchelonus bosonohyi sp. n.
Male
Head. In dorsal view roundly narrowed behind eyes, almost twice as broad as long (57 : 29), 1.2 times as broad as mesosoma. In frontal view 1.1 times as broad as high. Ocelli small, not widely separated, POL = 1.5 times OOL. Temples as long as LO. Antennae with 23 segments, almost as long as body length; scape 3 times as long as wide; 1st flagellar segment about 3.5 times as long as wide, apical segments 2-2.5 times as long as wide.
Mesosoma. In dorsal view almost as broad as carapace. In lateral view 1.8 times as long as high and almost as long as length of carapace.
Wings. Radial cell in forewing comparatively large, its length along the metacarp as long as pterostigma. Second radio-medial cell half the size of the radial cell. Second radial abscissa as long as first abscissa, 4 times shorter than third abscissa.
Legs. Hind femora 3.5 times as long as broad. Outer spur of hind tibiae longer than inner spur, almost reaching half of 1st metatarsal segment.
Metasoma. Carapace elongate, almost twice (95 : 48) as long as maximum breadth; apicoventrally incurved for one-tenth of its length. AMA oval and small, in rear view of posterior end about 0.27 of width of carapace
Sculpture. Head behind eye and face finely transversely striate. Frons with fine concentrical sculpture. Clypeus largely punctate and not shining. Mesonotum rugose punctate. Scutum anteriorly granulate punctate, area before scutellum with some rugae. Scutellum largely not roughly sculptured, centrally shining. Propodeum granulate rugose with transversal carina, lateral tubercles small. Carapace granulate with thin longitudinal undulations spanning half its lengthwise visible surface.
Colour. Body black. Labiomaxillary complex dark brown. Legs: fore coxae dark-brown, hind coxae black; fore femora brown with yellowish apices, hind femora dark-brown; fore tibiae yellowish, hind tibiae dark-brown with a central brown spot; all tarsi brown. Forewings slightly infuscate. Pterostigma, costal vein and and metacarpus brown, other veins brownish.
Body length: 3.1mm.
Taxonomic affinity and comparison. It resembles M. olgacola Tobias, from which it differs mainly in bigger body size, wider head than mesosoma (in olgcicola it is slightly narrower than mesosoma), and darker colouring of legs (in olgacola hind femora are entirely brown, while in bosonohyi they are entirely dark).
Etymology. The species name refers to the locality in Moravia where it was found.
Distribution. Czech Republic
Holotype: 1 (5), ČR, Moravia, Brno, Bosonohy, leg. Fr. Gregor, 4.vi.l939, ['6-dentata'] ['semicincul' ♂22].
Data used in the multi-access key
These data are collected from the species descriptions and redescriptions, from published figures and photographs and from own measureements and observations. For a description of the different variables and value classes see this
pdf.
morphology |
basic information | female | male |
body length (mm): | (2.8) 2.8 - 3.3 (3.4) | (2.8) 2.8 - 3.3 (3.4) |
number of antennal segments: | 16 | (22) 22 (24) |
head, dorsal view |
Head width : length | wide | wide |
Temples narrowing - widening | parallel | parallel |
Eye length : temple length | 0.75 - 1.0, 1.0 - 1.25 | 0.75 - 1.0, 1.0 - 1.25 |
Roundness temple | strong, medium | strong, medium |
POL : OD | > 4 | > 4 |
Ocellar triangle shape | very wide | very wide |
Excavation of head | 25 - 35%, > 35% | 25 - 35%, > 35% |
head, lateral view |
Head height : length | very long | very long |
Eye height : length | short | short |
Temple length : eye length | short | short |
head, frontal view |
Head width : height | very narrow, narrow | very narrow, narrow |
Face width : height | narrow, wide | narrow, wide |
Eyes converging ventrally | about parallel | about parallel |
EH : MSL | very short | very short |
Clypeus width : height | quadrangular | quadrangular |
Clypeus extending above bottom of eyes | far below, below | far below, below |
Tentorial pits | very small, small | very small, small |
Shape of lower margin clypeus | convex | convex |
antennae |
Antennal shape | --- | filiform, not widened |
Segment 3 length : width | --- | medium, long |
Penultimate segment length : width | --- | long |
Length of antenna : length of body | --- | 3: long, 4: very long |
mesosoma, lateral view |
Length : height | long | long |
transverse carina | present | present |
lateral teeth | weak, small, short | weak, small, short |
mesosoma, ventral view |
Prepectal carina lamelliform | indistinct | indistinct |
legs |
Hind femur length : width ratio | medium | medium |
Hind tibia length : hind tarsus length ratio | --- | --- |
Hind tibia (longest) spur length : metatars length ratio | short, long | short, long |
wings |
Vein 1-R1 length : pterostigma length | long | long |
Vein r length : vein 3-SR length | short | short |
Shape vein SR1 (straight / concave / convex) | concave, slightly concave | concave, slightly concave |
S-shape vein SR1 | apically convex | not S-shaped |
cell M : cell Sm2 | Sm2 medium | Sm2 medium |
Pterostigma length : width ratio | short, medium | short, medium |
Angle between radial vein (r) : vein 1-R1 | medium, blunt | medium, blunt |
metasoma, dorsal view |
Length : width ratio of metasoma | medium, long | medium, long |
Shape of metasoma | widest in middle | widest in middle |
metasoma, lateral view |
Length : height ratio of metasoma | medium, long | medium, long |
posterior : anterior height ratio of metasoma | small, medium | small, medium |
Position of maximum height | medium, medium-posterior | medium-posterior |
metasoma, ventral view |
Metasoma posteriorly curved forwards | just/slightly incurved | just/slightly incurved |
male apical aperture |
Aperture width : metasoma width | no aperture | no aperture |
Aperture shape | n. a. | n. a. |
Median process shape | n. a. | n. a. |
sculpture |
head |
general coarseness | fine | fine |
clypeus |
coarseness punctation | punctate | punctate |
density punctation | --- | --- |
face |
sculpture type | striate | striate |
sculpture direction | transverse | transverse |
vertex and temple |
sculpture type | striate-rugulose | striate-rugulose |
mesonotum |
sculpture type | notauli distinct | notauli distinct |
scutellum |
middle | smooth | smooth |
lateral | rugulose | rugulose |
metasoma |
base - mid sculpture | longitudinally rugose / rugose-striate | longitudinally rugose / rugose-striate |
sculpture at apex | rugulose, smooth | rugulose, smooth |
coarse / fine boundary | base (to 50%) | base (to 50%) |
color |
head |
mandibles color pattern | entirely dark | entirely dark |
palpi, lightest color | black, dark brown | black, dark brown |
antennae |
scapus, lightest color | black, dark brown | black, dark brown |
segment 3 and 4, lightest color | black, dark brown | black, dark brown |
legs |
fore coxae lightest colour | dark | dark |
fore femur lightest colour | medium light | medium light |
fore femur color pattern | tip light | tip light |
hind femur lightest colour | dark | dark |
hind femur color pattern | entirely dark | entirely dark |
hind tibia lightest colour | medium dark | medium dark |
hind tibia color pattern | narrow light ring | narrow light ring |
hind basitarsus lightest colour | medium dark | medium dark |
hind tarsus segment 2-3 lightest colour | medium dark | medium dark |
wings |
middle veins lightest colour | medium dark | medium dark |
basal veins lightest colour | medium light | medium light |
metasoma |
metasoma colour pattern | entirely dark | entirely dark |
metasoma lightest colour | dark | dark |
metasoma base, colour pattern | entirely dark | entirely dark |
metasoma base, light spots | n.a. | n.a. |
metasoma base, light band | n.a. | n.a. |
Chelonus bosonohyi in published keys
T14: Tobias, 2010
Palearctic species of Microchelonus Szépligeti (Hymenoptera: Braconidae, Cheloninae): key to species.
